01201987 Vertiv GXT5-20KIRT9UXLN
Liebert GXT5 Online 20kVA UPS - 230V Single Phase - LCD PF1.0 - 9U Extended Run Rack/Tower - RDU101 Webcard & Rail Kit Bundled - 3 Year Warranty.
The Vertiv™ Liebert® GXT5 UPS is a single phase, online double conversion UPS solution which offers robust power outage protection and continuous power conditioning in a compact and flexible deployment system. Liebert GXT5 is ideally suited to protect critical infrastructure in both centralized and edge network applications. Liebert GXT5 comes with various models ranging from 750VA to 20kVA and in both tower or rack form factor.
The Liebert GXT5 UPS is ideally suited for:
- Banking, Financial and Insurance- Data Center/ Colocation / Hosting
- Education- Government
- Healthcare
- Manufacturing
- Retail and Wholesale
- Telecom
- Transportation
| Form Factor: | Tower / Rack Mountable |
| Capacity: | 10000VA / 10000W |
| Input Voltage: | 288 VAC |
| Output Voltage: | 200/208/220/230/240 |
| Power Factor: | 1 |
| Rated Frequency: | 40Hz to 70Hz |
| Efficiency: | 95.9% Online; 99% ECO mode |
| Waveform: | Pure Sine Wave |
| Product Dims & Weight: | 430 x 630 x 394mm @ 135.2kg |
| Shipping Dims & Weight: | 810 x 1200 x 720mm @ 190kg |
| Operating Temperature: | Full power up to 40 ºC (up to 50 ºC with derating) |
| Maintenance Bypass: | Incorporated |
| Warranty: | 3 Years |
| Inlet: | Hard-wire or Optional PODs |
| Outlets: | Hard-wire or Optional PODs |
| Batteries: | 16 x 12V x 9.0 AH |
| External Battery: | GXT5-EBC384VRT6U |
| Relay Card: | IS-RELAY |
| Runtime tool: | Available here (Right click to open link in new tab) |
| Webcard: | RDU101 Included |
| Mounting Rail Kits: |
Rack Slide Rail Kit Included |
